Extremely compact, reliable and versatile fanless embedded computer providing high processing power with low power consumption. A rugged construction combined with multiple I/O connectivity makes this computer ideal for applications where space is severely restricted, such as machine automation, kiosks, access control and remote monitoring.
The EFC-206 has an ultra-compact of footprint of 116mm x 110mm, meaning it can be easily installed in applications where space is restricted.
The low power Intel® Atom™ processor keeps upfront and through life costs to a minimum. The processor is optimised for energy efficiency, ensuring low thermal output and meaning the EFC-206 can be specified with minimal impact on install location. Integrated Intel® HD graphics equip the platform to deal with demanding graphic applications.
The EFC-206 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
The chassis is compatible with DIN, VESA and wall-mounting, ensuring the EFC-206 can be integrated into your desired environment with minimal time and effort.
Mini-PCIe expansion capabilities and an external Wi-Fi antenna allow the EFC-206 to fulfil a range of applications including remote monitoring and access control.
| CPU | Intel© Celeron N2930, 1.83Ghz quad core |
| Memory | 2GB DDR3, expandable to 8GB |
| Storage | 1 x mSATA |
| Graphics | Intel© HD graphics |
| Expansion | 1 x mini-PCIe Slot (half size) |
| LAN / I/O | 2 x Gigabit LAN ports; optional WiFi / 1 x RS232/422/485; 1 x USB 3.0; 3 x USB 2.0 |
| Video / Audio | 2 x HDMI / 1 x line out |
| Operating System | Win 7/8/10; Linux |
| Input Voltage | 12 VDC; AC Adapter, 36W |
| Dimensions | 116mm (W) x 49mm (H) x 110mm (D) |
| Weight | 0.9kg |
| Operating / Storage Temperature | Op: 0°C ~ 40 / Storage: -20°C to 80°C |
| Construction | Aluminium |
| Ordering Information | EFC-206: N2930 EFC-206W: N2930 with WiFi |
