We offer a fully managed service including vehicle surveys, supply of all hardware, on-site installation, multiple warranty options and returns servicing.
Your tablet can be quickly and easily charged and connected to external devices. This saves time with all connections made simultaneously when the tablet is docked.
Expanding the tablet’s existing I/O, the dock can provide two serial, one Ethernet, one USB 3.0, three USB 2.0, one HDMI, one VGA, one headphone and one microphone ports. Additional interfaces can be designed into the device using our Tablet+ service.
The dock fits all configurations of the Getac F110 fully rugged tablet, accommodating MSR and hand strap accessories.
Designed and built by Gamber-Johnson, a leading supplier of rugged computer mounting systems since 1954. Gamber-Johnson is an ISO 9001:2008 certified company, and all of its products are MIL-STD-810G and SAE J1455 rated, trusted globally by oil and gas, police, and military organisations globally.
The dock offers a steady and reliable platform for your Getac device, while maintaining full usability and functionality. Additionally, your tablet can be locked in place, preventing theft.
| Compatibility | Getac F110 |
| LAN | 1x RJ45 LAN port |
| I/O | 1x USB 3.0, 3x USB 2.0, 2x Serial, 1x RJ45, 1 VGA, 1X HDMI, 1x Headphone jack, 1x Microphone jack, 1x triple-RF external antenna pass through |
| Input Voltage | 19 VDC |
| Mounting | Mountable in a wide range of vehicles |
| Dimensions | Docks: 224m W / 291mm H / 94mm D |
| Weight | Docks: 1.6kg |
| Construction | Aluminium and composite |
| Functional Shock | MIL-STD-810G |
| Mechanical Shock | MIL-STD-810G |
| EMC Testing | EN 55022:2010/AC:2010 |
| Impact – Crash Hazard | SAE J1455 |
| Vibration | MIL-STD-810G |
| Electrostatic Discharge | ISO 10605 |
| Certification | RoHS, FCC, CE, Environmental: High/Low temperature – |
| Ordering Information | 7160-0542-00 (No RF pass through) |
