Robust, highly configurable and specified with extreme 8 core i7 processing power, this computer is the most expandable in our machine vision range. The rackmountable MVC-431 packs in as much as I/O and expandability into a 3U form factor as is possible, making it ideal for applications requiring high performance in a compact footprint.
The MVC-431 is supported by Intel’s most powerful range of X-Series processors specifically designed for 4K, vision and artificial intelligence applications. These multi-core, high frequency CPUs enable superior computational performance in demanding vision applications.
With up to 28 lanes of PCI Express, the MVC-431 is configurable with a host of single or multi card GPU or FPGA configurations to enable high performance.
The MVC-431 features a robust, industrial grade chassis designed to increase product lifespan when deployed in demanding and challenging industrial environments. The chassis depth of 400mm is suitable for deployment in locations where a typical rackmount chassis would be too deep.
The MVC-431 has been designed with operational run-time and product availability in mind while high grade components with high thermal tolerance enable 24/7 operation.
We have developed the MVC-431 using industry standard form factors, affording the ability to move the computer in line with technology updates whilst still servicing and upgrade units already in deployment.
The MVC-431 design can be modified from MOQs as low as ten, without incurring engineering charges for alterations including custom branding and further ruggedisation.
| CPU | Intel Core i7-7820X, 8 Core, up to 4.3GHz |
| Memory/Storage | 8 x 16GB DDR4 2666MHz RAM (128GB) |
| Storage | 2 x 1TB SATA HDD (fixed) |
| Graphics | NVIDIA GeForce 210 1GB DDR3 DVI/VGA/HDMI |
| Expansion | 3 x PCIe 3.0 x16 |
| LAN | 2 x gigabit Ethernet LAN |
| I/O | 2 x USB 3.1 |
| Video / Audio | 1 x DVI-D: up to 1920 x 1200 @ 60Hz |
| Operating System | Windows 10 |
| Input Voltage | 100-240VAC |
| Power Supply | 700W 2U high efficiency 80PLUS |
| Dimensions | 483mm (W) x 400mm (L) x 133mm (H) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Certification | CE, FCC |
