e-Mark compliant fanless vehicle computer with multiple video inputs optimised for video surveillance. A rugged construction with multiple PoE connectivity offers video capture from multiple IP cameras and options for multiple analogue cameras. Additional serial and digital I/O extends capabilities into other functions, such as control and monitoring.
The VCE-21 complies with the e-Mark safety regulation, making it ideal for in-vehicle installations.
The VCE-21 has an operating temperature range of -20°C to 55°C, providing extended operational life in applications with challenging temperature demands.
Designed and manufactured to military standards, the VCE-21 can be installed in applications where shock and vibration are prominent, without compromising performance or reliability.
The 9-36V DC input power provisions for inconsistent power sources, achieving compatibility with a variety of applications and larger equipment installations.
Industry-leading performance with Intel® Core i technology. The VCE-21 features a powerful 1.7GHz Intel© Core i7 for superior processing power and graphics performance.
Customisable expansion including your choice of PoE ports, video inputs, CAN bus and SIM card ensures the VCE-21 will meet your exact performance requirements.
The VCE-21 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
| CPU | Intel© Celeron 847E, 1.1GHz |
| Memory / Storage | Up to 8GB DDR3 |
| Storage | 1 x 2.5” SATA SSD/HDD removable, lockable 1 x compact flash socket |
| Graphics | Intel© HD graphics |
| Expansion | 2 x Mini PCIe with SIM card slots (VCE-210/211), 3 x mini-PCIe, 2 with SIM card slots (VCE-212/213) |
| LAN | 4 x Gigabit LAN Port with PoE, 1 x gigabit LAN (VCE-212/213-B2) |
| I/O | 1 x CAN bus (VCE-212/213-B2) / 8 x Analogue Video Inputs (VCE-210-A1/211-A5), 16 x Analogue Video Inputs (VCE-210-A2/211-A6), 1 x RS232/422/485, 4 x USB, 6 x DI, 6 x DO |
| Video / Audio | 1 x HDMI, 1 x DVI-D, 1 x VGA / 1 x mic in, 1 x line out |
| Operating System | Win XP/7/8/10, Linux |
| Input Voltage | 9-36 VDC |
| Dimensions | 274mm (W) x 72mm (H) x 188mm (D) |
| Construction | Aluminium |
| Operating Temperature | -20°C to 55°C |
| Shock / Vibration | MIL-STD-810G, method 516.6 / MIL-STD-810G, method 514.6 |
| Certification | CE, FCC Class A, E13 |
